Curved Staircase
  • Curved Staircase
Curved Staircase

Curved Staircase

Model: PY-CS07

The structure consists of 200*100*10mm mono center stringer

The color of the stringer can be powder coated black, white, sliver and grey or supplied brushed or polished stainless steel.

Treads:Rubber wood(Thailand Oak),Oak, Beech, Maple, Ash, Birch, Walnut, Teak.

Treads are either supplied matt varnished, oiled or stained in the factory and sometimes left untreated to be stained on site.

The balustrade itself is in-filled by either:

Horizontal Stainless Steel Rails

Framed Glass Infill Panels With Stainless Post

Frameless Glass Panels Bolted Directly To The Side Of The Stringer And Hardwood Treads

Framless Glass Panel Put Into The U Channel Stringer With Rubber

Product Details
Floor to floor heightCustomized
Stair WidthCustomized
Clear Tread WidthCustomized
Tread Type40mm Oak-Painted
Balustrade Type12mm tempered glass-Clear
HandrailDiameter 50.8mm fascia mounted handrail– Brushed
Stair Stringer200*100*10mm mono center stringer
Finish of Steel

Brushed/Polished Stainless Steel

Powder Coated Steel

AdditionalAll main components can be customized

To keep the flight open and light whilst adhering with the 100mm gap rule – there are the following solutions:

· Steel Riser Bars

· L shaped treads with timber downstand

· Half Glass Riser Pieces

· Full Glass Riser

· Full closed risers with timber

The riser height, pitch angle and going depth are created specifically to suit the opening, staircase configuration and floor to floor height of the project. The stair is ‘dry’ fitted in the factory before dispatch to ensure all parts fit together.
